H_1*NDI input card

The NovaStar H1xNDI Input Card is designed for integration with NovaStar's H Series Video Wall Splicers, including models such as the H2, H5, H9, and H15. This card facilitates the direct input of NDI (Network Device Interface) streams into the video wall system, offering high-quality, low-latency video transmission over IP networks.

NOVASTAR

Key Features:

• Connector:
  • 1x RJ45 Ethernet port


• Supported NDI Formats:
  • NDI|HX
  • Full NDI


• Decoding Capabilities:
  • Supports up to 1x 4K×2K@60Hz stream
  • Alternatively, supports 2x 4K×2K@30Hz streams
  • Or 4x 2K×1K@60Hz streams


• Network Settings:
  • Configurable IP address, subnet mask, and gateway
  • DHCP support for automatic IP configuration


• Additional Features:
  • Customizable NDI channel naming for easy identification
  • LED indicators to display connection and data transmission status
