NovaStar MEE200 Technical Specifications

General Overview:

• 3 × HDMI 1.3 inputs: Resolutions of each input up to 1920×1080@60Hz.
• 8 × 1G Ethernet outputs: Efficient data distribution to LED displays.
• 5 × USB 2.0 and 1 × USB 3.0 ports: For multimedia playback and function extension.
• 3.5-mm internal and external audio connectors: Supports audio connectivity for various devices.
• Local and online playback: Supports high-definition videos, including 4K HDR videos.
• Dual wireless network card: Allows for Wi-Fi and wireless hotspot connections simultaneously.
• Bluetooth 4.0 support: Compatible with Bluetooth mouse, keyboard, speaker, and other common peripherals.
• Bluetooth remote: Allows omnidirectional remote control.
• 4 × relays: For power management of the LED display.
• Wireless screen mirroring: Supports screen mirroring from Windows, Mac, iPhone/iPad, and Android devices.
• 1 × reserved OPS control port: For OPS computer connection to control its power on/off.
• OSD menu: User-friendly menu interface for operation.
• Compatible with conference room peripherals: Camera, speaker, laser pointer, and more.

Image and Display Features:

• 18Bit+ high grayscale: Works with the A8s or A10s Plus receiving card to address grayscale loss due to low brightness, enabling smooth images.
• Precise grayscale technology: Fixes issues like grayscale spikes, color cast, and mottling, ensuring more accurate display performance.
• Color management: Prevents color distortion when working with the A8s or A10s Plus receiving card.
• HDR support: Enhances image quality for more vivid and realistic visuals with clearer details when working with the A8s or A10s Plus receiving card.
• Pixel-level calibration: Supports brightness and chroma calibration when working with NovaLCT and NovaCLB for precise visual adjustments.

Power and Connectivity:

• Power Input: AC 100-240V, 50/60Hz for global compatibility.
• Power Consumption: Energy-efficient for low power usage and reduced operational costs.
