NOVASTAR MRV 210
Novastar MRV210-1 LED Display Receiving Card
Description:
The Novastar MRV210-1 is a specialized LED display receiving card designed for high-resolution applications. It supports a resolution of 256x226 pixels and is equipped with 24 groups of RGB data. This card supports pixel-level brightness and chromaticity calibration, providing precise and consistent display performance. The MRV210-1 also includes monitoring functions for cabinet temperature, voltage, and overall working condition to ensure reliable operation.
Although it does not support connected monitoring cards, lamp panel Flash, or integrated HUB, it remains an efficient solution for high-resolution LED displays. The MRV210-1 is certified for EMC, CE, and RoHS compliance, ensuring it meets international standards for safety and electromagnetic compatibility.
Key Features:
- Resolution Support: 256x226 pixels.
- RGB Data Output: Supports 24 groups of RGB data.
- Calibration: Supports pixel-level brightness and chromaticity calibration for improved display quality.
- Monitoring: Monitors cabinet temperature, voltage, and working conditions for reliable performance.
- Certification: Complies with EMC, CE, and RoHS standards.
- No Integrated HUB or Lamp Panel Flash: Does not include integrated HUB or lamp panel Flash capabilities.
- No Monitoring Card Support: Does not support connected monitoring cards.
Parameter:
| Parameter | Value |
|---|---|
| Resolution | 256 x 226 pixels |
| RGB Data | 24 groups |
| Calibration | Pixel-level brightness and chromaticity calibration |
| Monitoring | Cabinet temperature, voltage, and working condition monitoring |
| Monitoring Card Support | Not supported |
| Integrated HUB | None |
| Lamp Panel Flash | Not supported |
| Certification | EMC, CE, RoHS |
