NOVASTAR MRV300

Novastar MRV300-4 Control System Receiving Card

Description:

The Novastar MRV300-4 Control System Receiving Card is part of Nova's advanced control system product line, designed to handle high-resolution display requirements. It supports up to 16 groups of RGBR data or 20 groups of RGB data, with a maximum resolution of 256x226. The card provides excellent functionality, including pixel-level brightness and chromaticity calibration, power supply voltage monitoring, and Ethernet communication status detection. It also complies with EU RoHS and CE-EMC standards for safety and compatibility.

Key Features:

• RGB Data Output: 16 groups of RGBR or 20 groups of RGB data output.
• Serial Data Output: 64 groups of serial data output.
• Resolution Support: 256x226 resolution support.
• Configuration File Readback: Supports configuration file readback.
• Monitoring Features: Includes temperature monitoring, power supply voltage detection, and Ethernet cable communication status detection.
• Pixel-Level Calibration: Supports pixel-by-pixel brightness and chromaticity calibration.
• Pre-stored Settings: Supports pre-store picture settings.
• Compliance: Complies with EU RoHS and CE-EMC standards.

Recognition Models:

To meet the needs of different customers, Nova provides several specific models of the MRV300 product series. These include standard products in stock and customized models as required:

• MRV300-1: Standard model, male connector on top.
• MRV300-2: Male connector on bottom.
• MRV300-3: Female connector on top.
• MRV300-4: Female connector on bottom.

Parameter:
