NovaStar MX40 Pro Specifications

Overview:

The NovaStar MX40 Pro is an advanced video processor equipped with multiple input and output options for handling high-definition video signals. With robust features like HDR10 support, Genlock, dynamic boosting, and integrated network switches for cascading, it is a high-performance solution for complex video applications.

Key Features:

Inputs:

• 3x HDMI 2.0 (max. 4096×2160@60Hz or 8192×1080@60Hz)
• 1x DP 1.2 (max. 4096×2160@60Hz or 8192×1080@60Hz)
• 1x 12G-SDI (max. 4096×2160@60Hz), supports ST-2082, ST-2081, ST-424 & ST-292

Outputs:

• 20x LED-Out (RJ45)
• 8Bit@60Hz: 650,000 pixels
• 10Bit@60Hz: 480,000 pixels (Only in combination with A10s Pro Receiving card)
• 10/12bit@60Hz: 325,000 pixels
• 3x HDMI 2.0 Loop
• 1x 12G-SDI Loop
• 4x OPT-Out (10G)

Additional Features:

• Genlock
• Color Processing: Color Replacement, Color Correction, 3D LUTs, Color Curves
• Dynamic Booster
• Grayscale calibration
• Brightness & Chroma Calibration
• HDR10 support
• Low latency
• 3D capable
• Integrated network switch for cascading multiple devices

General Specifications:

• Supply Voltage: AC 100-240V, 50/60HZ
• Dimensions: 482.6 x 467.0 x 94.2 mm (WxDxH)
• Power Consumption: 70W
• Weight: 7.5kg
