NovaStar MX6000 Pro Specifications

Overview:

The MX6000 Pro is an 8K LED display controller that belongs to NovaStar's COEX series. The device offers a wide range of options with up to seven different input cards that support 8K, 4K, and VoIP. These cards can be flexibly configured to provide bandwidths of 1G or 5G for signal transmission. In addition, the device supports the configuration of backup scenarios and can switch back and forth between individual devices without interruption. The device is operated with the new VMP software from NovaStar.

Hardware Features:

Inputs:

• 8x slots for the following input cards:
• 4x HDMI 2.0
• 2x HDMI 2.1
• 2x DP 1.4
• 1x SMPTE ST 2110 (25G)
• 1x NDI

Outputs:

• 8x slots for the following output cards:
• 1x 40G Fiber Output
• 4x 10G Fiber Output

Further Features:

• Real-time preview & monitoring
• Supports frame rates of up to 360Hz
• Each output card supports 4 layers (32x 4K layers in total)
• Color Replacement
• 14Ch Color Correction
• Color Curves
• 3D LUT
• Dynamic Booster
• HDR
• Frame Rate Adaptive
• Shutter Fit
• Full-Grayscale Calibration

General Specifications:

• Supply Voltage: AC 100-240V, 50/60HZ
• Power Consumption: 625W
• Dimensions: 482.6 x 282.9 x 538.8 mm (WxDxH)
• Weight: 31kg (without cards)
