Description of NovaStar TCB300

Main Outputs:

• Main Output Connector: TRS balanced 3.5 mm
• HDMI 1.3 (Loop): 1

Processor & Memory:

• Processor: 1.2 GHz
• Operating Memory: 1 GB
• Internal Storage Space: 32 GB

Local Content Upload:

• Ethernet: Yes
• USB: Yes

Software Specifications:

• Control Software: VIPLEX Express, VIPLEX Handy, VNNOX

Wireless Specifications:

• Wi-Fi Mode: AP

Extra Features:

• Scaling Function: Yes

Electrical Specifications and Connections:

• Power Supply: 100-240 V AC 50/60 Hz
• Power Consumption: 15 W
• Data Connector In: RJ45, USB
• Data Connector Out: HDMI

Mechanical Specifications:

• Width (Including Handles): 196 mm (7.717″)
• Width (Without Handles): 159 mm (6.26″)
• Height (Without Handles): 34 mm (1.339″)
• Depth (Without Handles): 116 mm (4.567″)
• Weight: 0.35 kg (0.772 lb)
• Housing: Plastic
• Colour: Black

Thermal Specifications:

• Maximum Ambient Temperature: 60 °C (140 °F)
• Minimum Ambient Temperature: -20 °C (-4 °F)
• Operating Humidity: 0-80 %rH

Included Items:

• Included Accessories: WiFi antenna
