Parameter |
Value |
|
Pixel Pitch |
3.91mm |
|
LED Type |
SMD1921 |
|
Brightness |
3500 cd/m² |
|
Module Size |
250x250mm |
|
Panel Weight |
0.49kg |
|
Pixel Density |
65536 pixels/m² |
|
Pixels Per Panel |
64 x 64 pixels |
|
Hub |
HUB75 |
|
Mask |
Support |
|
Single-dot Brightness Calibration |
Support |
|
Brightness |
3500 cd/m² |
|
Color Temperature |
6500K (1000K ～ 9500K Adjustable) |
|
Beam Angle (Hor/Ver ° ) |
140° / 120° |
|
Brightness/Color Uniformity |
≥98% |
|
Contrast Ratio |
5000:1 |
|
Max Power Consumption of Module |
≤31.5W |
|
Input Power |
630 W/ m² |
|
Input Power |
189 W/ m² |
|
Power Supply Input Voltage |
AC90～132V/ AC186～264V, Frequency 47-63（Hz） |
|
Frame Changing Frequency |
60Hz |
|
Refresh Rate |
3840Hz (Standard) / 7680Hz (Optional) |
|
Processing Depth |
12 ～14 Bit |
|
Video Support |
2K / 4K |
|
Life Span (hrs) |
100000hrs |
|
Working Temp/Humidity (℃/RH) |
-20℃~50℃ / 10%~80%RH (No Condensation) |
|
Storage Temp/Humidity (℃/RH) |
-20℃~50℃ / 10%~80%RH (No Condensation) |
|
Certification |
CE/CB/RoHS/EAC |
Note
1. Product pictures are for illustration only, the actual product effects (including but not limited to appearance, color, size) may be slightly different, please refer to the actual product.
2. The specification parameters are reference values. Part of the data comes from Unilumins internal laboratory and is obtained under a specific test environment. In actual use, it may be slightly different due to product batch differences, configuration differences, software versions, use conditions and environmental factors. Actual usage shall prevail.
3. Different configurations can achieve different refresh rates.
